Description

Reviews

Rated Voltage	220/380V, 230/400V, 380/660V, 400/690V or customized
Rated Output Power	11KW/15HP
Rated Speed	1500rpm
Rated Frequency	50HZ, 60HZ or 50/60HZ
Connection	Star for 3KW and below
Connection	Delta for 4KW and above
Duty Type	S1 Continuous
Cooling Method	IC411
Insulation Class	IP54 or IP55
Ambient Temperature	-15~40℃
Altitude	Up to 1000m Above Sea Level
Color	Blue, Black or Grey

TECHNICAL DATA

Type

FRAME SIZE

MOUNTING DIMENSIONS

OVERALL DIMENSIONS

HMA5

160M

254

108

110

160

M16x36

350

300

250

320

330

255

415

760

HM5 (4POLE 1500RPM) Parameters TECHNICAL DATA

Type

Ouput

Speed

Efficiency

Power
factor

Rated current

Ts/Tn

Tmax/Tn

Is/In

ALU

C/I

(kW)

(rpm)

(%)

Cosφ

380V

400V

415V

(Kg)

HM5

160M-4

1475

94.6

0.85

20.8

19.7

19.0

2.2

2.3

9.5

167
