| Rated Output Power | 110KW/150HP |
| Rated Speed | 1500RPM |
| Rated Voltage | 220/380v,230/400V,380V/660V,400/690V,220/440V,230/460V or Customized |
| Rated Frequency | 50Hz,60Hz or 50/60Hz |
| Duty Type | S1 Continuous = |
| Insulation Class | F or H |
| Protection Class | IP54 or IP55 |
| Cooling Method | IC411 |
| Ambient Temperature | -15~40℃. |
| Altitude | Up to 1000m Above Sea Level |
| Colour | Black,Blue,Grey |
| Model | Rated Power | Rated Speed (rpm) | Efficiency η (%) | Efficiency at 75% Load (%) | Efficiency at 50% Load (%) | Power Factor cosφ | Rated Current (A) | Rated Torque (N·m) | Locked - Rotor Torque / Rated Torque | Maximum Torque / Rated Torque | Locked - Rotor Current / Rated Current | Aluminum Shell Weight (kg) | Cast Iron Shell Weight (kg) | |||
| kW | Hp | 380V | 400V | 415V | ||||||||||||
| HM3 - 315S - 4 | 110 | 150 | 1485 | 95.2 | 95.2 | 93.3 | 0.89 | 197 | 187 | 180 | 706.0 | 2.0 | 2.2 | 7.0 | 955 | |
| Frame Size | Mounting Dimensions | Overall Dimensions | ||||||||||||||||||
| B5 | ||||||||||||||||||||
| A | B | C | D | E | F | G | H | K | Z | P | M | N | S | T | AB | AC | AD | HD | L | |
| 315S(4-10P) | 508 | 406 | 216 | 80 | 170 | 22 | 71 | 315 | 28 | M20×42 | 660 | 600 | 550 | 8-Φ24 | 6 | 635 | 600 | 540 | 855 | 1210 |
