Description

Reviews

Rated Output Power	7.5KW/10HP
Rated Speed	1500RPM
Rated Voltage	220/380v,230/400V,380V/660V,400/690V,220/440V,230/460V or Customized
Rated Frequency	50Hz,60Hz or 50/60Hz
Duty Type	S1 Continuous
Insulation Class	F or H
Protection Class	IP54 or IP55
Cooling Method	IC411
Ambient Temperature	-15~40℃
Altitude	Up to 1000m Above Sea Level
Colour	Black,Blue,Grey

HMA3/HMA4 Parameter OUTLINE DIMENSIONS-B3,B5 AND B35

Type

FRAME SIZE

MOUNTING DIMENSIONS

OVERALL DIMENSIONS

HMA3

HMA4

132M

216

178

132

M12x28

300

265

230

270

255

187

319

550


HM3 (4POLE 1500RPM) Parameter TECHNICAL DATA

Type

Ouput

Speed

Efficiency

Power
factor

Rated current

Ts/Tn

Tmax/Tn

Is/ln

ALU

C/I

(kW)

(rpm)

(%)

Cosφ

380V

400V

415V

(Kg)

HM3

132M-4

7.5

1460

90.4

0.84

15.0

14.3

13.7

2.3

7.5
