Rated Voltage	220/380V, 230/400V, 380/660V, 400/690V or customized
Rated Output Power	3KW/4HP
Rated Speed	3000rpm
Rated Frequency	50HZ, 60HZ or 50/60HZ
Connection	Star for 3KW and below
Connection	Delta for 4KW and above
Duty Type	S1 Continuous
Cooling Method	IC411
Insulation Class	IP54 or IP55
Ambient Temperature	-15~40℃
Altitude	Up to 1000m Above Sea Level
Color	Blue, Black or Grey

TECHNICAL DATA

TYPE

MOUNTING DIMENSIONS

B14-A

OVERALL DIMENSIONS

HMA5

100L

160

140

100

M10×22

130

110

4-M8

3.5

200

193

145

2454

428

HM5 (2POLE 3000RPM) Parameters TECHNICAL DATA

Type

Ouput

Speed

Efficiency

Power
factor

Rated current

Ts/Tn

Tmax/Tn

Is/In

ALU

C/I

(kW)

(rpm)

(%)

Cosφ

380V

400V

415V

(Kg)

HM5

100L-2

2935

91.1

0.87

5.75

5.46

5.27

2.2

2.3

9.5
